SOAP vs REST: Comprehensive Difference Between Web Services

Author
SPEC INDIA
Posted

February 10, 2022

Updated

August 16th, 2023

There was a time when data exchange between applications was carried out using file transfers.

File transfers have taken a back seat and data exchange has changed to the point where message-based communication and request-response between applications are a part of a routine.

Cloud infrastructures and advanced web development standards have played important roles in the new designs of data exchange that have made data exchange easier and faster.

At present, web services are the most commonly used data exchange methods that allow two devices or client-server applications to communicate with each other. Web services are commonly referred to as API – application programming interfaces and we can say that all web services are APIs. However, not every API is a web service.

In this article on SOAP vs REST, we will cover

  • What is a web service?
  • What is an API?
  • What is SOAP API?
  • What is REST API?
  • SOAP vs REST

Let’s start with the basic concepts and then we will see the difference between SOAP and REST.

What Is Web Service?

A web service is a collection of open protocols and standards that facilitate communication between systems or applications over the network. Software applications in various programming languages running on different platforms use web services to exchange data and communicate over computer networks.

Fundamental Characteristics of Web Service:

  • Self-describing, modular, distributed, self-contained, and dynamic
  • Built on top of open standards – HTTP, HTML, XML, TCP/IP, Java
  • Accessible via the Internet or private networks
  • Language and system independent
  • SOAP and REST are the two most popular and widely used web services.

What Is An API?

API is the acronym for Application Programming Interface. It allows two services and products to interact with each other without any user intervention. Developers can simply use this interface to enable communication and don’t need to know how the APIs are implemented.

APIs, in short, let two pieces of software communicate.

Most web applications rely on this for communication and would not be possible to function without APIs. In today’s time, API adheres to REST principles and JSON format and is built for HTTP.

What Is SOAP API?

SOAP stands for Simple Object Access Protocol.

It is a messaging protocol specification that sends a message using HTTP and SMTP. It uses XML for its message format in message transmission.

SOAP allows systems and applications to authenticate, authorize, and communicate using Extensible Markup Language (XML). It enables clients to invoke web services and receive responses independent of platform and language.

As SOAP is a protocol, it has certain built-in rules and architecture that increase its complexity and make it verbose. While SOAP is less suitable for the general web service scenario, it is an ideal choice for enterprise applications.

The reason behind this is ACID compliance. SOAP standards offer built-in compliance that includes Atomicity, Consistency, Isolation, and Durability that ensure a higher level of safety and reliability. SOAP is favored by banks, large financial organizations, and organizations handling sensitive transactions.

What Is REST API?

REST stands for Representational State Transfer.

REST is a software architectural style that was created to guide the design and development of World Wide Web architecture. REST is truly a web service and facilitates client-server communications and architectures.

Thanks to HTTP protocols, REST offers simplicity, visibility, scalability, portability, and reliability. This is all achieved through REST principles that must be followed for the services to be called RESTful.

RESTful API uses HTTP methods to access resources through URLs (a reference to a web resource) and JSON or XML for transmission of data. JSON is a widely used and preferred data format as it is browser compatible and easy to work with.

REST is focused on the web, which means, REST architecture is specifically designed for the web with goals such as scalability of web interactions, independent deployments of components, uniform interfaces, and encapsulation.

REST is known for its faster execution and performance along with cacheability, use of layered architecture, and statelessness.

Now we have seen the basic introduction, let’s talk about the difference between SOAP vs REST API in detail.

SOAP-vs-REST

SOAP vs REST: Key Differences Between Two Paradigms

SOAP is a protocol.

REST is an architectural style.

This is the main difference between SOAP and REST.

On a granular level, REST and SOAP both are different paradigms. So, we can’t have a direct comparison of SOAP and REST. But, there are certain points based on which we can decide when to choose what.

SOAP vs REST: A Quick Comparison Of Two Different API Styles

Parameters SOAP REST
Definition Simple Object Access Protocol Representational State Transfer
Designed for Standard messaging protocol specification that defines rules for exchanging structured information in web services Architectural style and set of guidelines for creating stateless, reliable web services
Data Exchange Format Mainly XML HTML, XML, JSON, and plain text
Performance Slower due to XML parsing, protocol-agnostic and verbose Faster, reliable, and standard operations
Bandwidth Requires more bandwidth Requires less bandwidth and is easy to implement
Use SOAP can’t use REST REST can use SOAP protocol.
Security High security due to SSL and WS-Security. Built-in ACID compliance makes it suitable for sensitive information exchange SSL and HTTPS for secure, reliable, and faster communication
Caching API calls cannot be cached Provides cacheability
Transport Layer Protocol Can operate over any protocol such as HTTP, SMTP, TCP, and UDP The standard HTTP protocol and its methods
Execution Model SOAP is like an envelope REST is like a postcard
Methods WSDL and more technical details HTTP methods such as GET, PUT, POST, and DELETE to access resources via URLs
Approach Functional-driven Data-driven
Statefulness Stateless by default but also possible to make it Stateful Stateful – no server-side session information is retained by the server
Suitable for Enterprise-level apps and sensitive transactions like a bank, FinTech companies, etc. A truly web services API widely used and implemented for client-server architecture and public APIs
Principles Extensibility, neutrality, and independence Six major principles – Client-server architecture, statelessness, cacheability, code on demand, uniform interface, and layered system
What Are The Advantages Of SOAP Over REST?
  • Suitable for distributed and enterprise environments and applications that require a higher level of security
  • Built-in ACID compliance protects the integrity of data
  • Language, platform, transport-independent, and standardized protocol
  • Offers extensibility through WS-Addressing standards
Advantages Of REST Over SOAP:
  • Easy to implement and understand, and small learning curve
  • Optimized for the web, suitable for faster and more efficient data transmission
  • HTML, JSON, Plain text, and form data formats make it compatible with web browsers
  • Faster and simple due to the use of HTTP
  • Simple, reliable, scalable, and secure web API

SOAP vs REST: Explained In Detail

Both Perform Different Things:

SOAP is a protocol and more function-driven. A typical SOAP structure is made up of envelope, header, and body elements with WSDL (Web Services Description Language). SOAP is a protocol specification that defines messaging framework.

It evolved as a successor of XML-RPC.

REST played a crucial role in the design and development of the World Wide Web. REST is an architectural style that is more data-driven and designed for client-server architecture. It contains a set of guidelines for interactions between web components.

SOAP API performs an operation, REST accesses resources for data exchange through URI.

Security:

As we have seen in the table, SOAP is a good choice as it supports WS security. It is more descriptive and comprehensive than SSL. It ensures security for SOAP-based messages through principles of confidentiality, integrity, and authentication. Also, built-in ACID compliance makes it more secure.

Both REST and SOAP offer end-to-end encryption using HTTPS and SSL. REST works with HTTP requests and responses and relies on a stateless communication protocol. REST is less secure than SOAP.

How It Works:

REST makes use of URLs to access resources. A URL (Uniform Resource Locator) is a reference to a web source that specifies its location. SOAP transfers structured information in XML data format containing an envelope, header, and body. This envelope-style payload transport causes extra overhead and results in slower performance and more bandwidth.

On the other side, REST is lightweight, scalable, and not restricted to only XML data format. It is primarily used for web services and is faster to implement and execute. It consumes less bandwidth compared to SOAP.

Cacheability:

Cacheable data can be reused by the browser without making any calls or initiating another request to the server. This saves time, improves performance and resources. When using SOAP, responses are not cached at the HTTP level. In REST, cacheability is considered an important principle while implementing RESTful services.

Data Formats (Content-Type):

SOAP supports only XML whereas, in REST, it supports JSON, XML, HTML, and even plain text. Most new and public APIs are built using REST and JSON as both are lightweight and easier to implement.

It consumes less bandwidth and is easier to understand and write. JSON + REST, this combination is browser-friendly and that’s the reason it became a de facto standard for the majority of APIs and web services.

Implementation:

In order to be classified as a RESTful API, a system must follow six guiding constraints defined by REST. These six principles are:

  • Client-server architecture
  • Cacheability
  • Support for on-demand code
  • Use of a layered system
  • Uniform interface
  • Statelessness

On the other side, SOAP is highly extensible and can be used with other protocols and technologies. It relies heavily on XML and WSDL for data transmission.

SOAP vs REST Example

Here are examples of each to help you better understand the differences.

Here, we are trying to fetch details of the book based on the book’s name.

SOAP Example:

SOAP Request

<soapenv:Envelope xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/" xmlns:sch="http://www.soapexample.com/xml/books">
<soapenv:Header/>
<soapenv:Body>
<sch:BookDetailsRequest>
<sch:name>The Alchemist</sch:name>
</sch:BookDetailsRequest>
</soapenv:Body>
</soapenv:Envelope>

SOAP Response:

<soapenv:Envelope xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/">
<soapenv:Header/>
<soapenv:Body>
<ns2:BookDetailsResponse xmlns:ns2="http://www.soapexample.com/xml/books">
<ns2:Book>
<ns2:name>The Alchemist</ns2:name>
<ns2:author>Paulo Coelho</ns2:author>
<ns2:type>Novel</ns2:type>
</ns2:Book>
</ns2:BookDetailsResponse>
</soapenv:Body>
</soapenv:Envelope>
REST Example:

GET https://restexample.com/books?name=The%20Alchemist
{
"name": "The Alchemist",
"author": "Paulo Coelho",
"type": "Novel"
}

Which API Should You Choose And When?

When we are talking about Soap vs REST API, this question arises.

Generally, most developers choose RESTful architecture. REST is a more suitable architecture in the contexts like mobile app development, serverless computing, IoT, and feature-rich modern web development.

REST APIs are lightweight, easy to implement, and easy to understand. The majority of developers prefer REST API because of its simplicity, visibility, portability, performance, and scalability.

SOAP is more suitable in certain scenarios when you need to work with legacy systems, need to maintain a state of information, or build enterprise-level apps with power-packed security. You can use SOAP when security is your concern as it offers more secure transactions and ACID compliance – Atomicity, Consistency, Isolation, and Durability.

The choice of API usually depends on the type of project or requirement. Whatever you choose, if you follow best practices, it will save your time and increase speed and performance.

Soap vs Rest Web Services: Choose Based On Preference And Use Case

We have listed down the differences between SOAP and REST and as you can see, each is different. REST is designed for internet-scale client-server applications and has a layer of abstraction to facilitate large-scale data transmission.

REST can make use of SOAP protocol but SOAP can’t use REST as REST is an architectural style.

REST and SOAP both are different, built differently, function differently, and also be used in different scenarios.

The choice is quite easy because use cases of both are different and developers can identify when to use what based on the requirements.
